台湾317铸钢蝶阀
中国台湾317铸钢蝶阀
BF-WCB-26N (LEVER)BF-WCB-26S (LEVER)BF-WCB-26M (LEVER)BF-WCB-28G (GEAR)BF-WCB-28S/BF-WCB-28M (GEAR)(BF-WCB-26N/26S/26M/28G/28S/28M) CAST STEEL BUTTERFLY VALVE WAFER TYPE LEVER & GEAR OPERATEDMODEL:BF-WCB-26N/26S/26MWAFER type LEVER operatorBF-WCB-28G/28S/28MWAFER type GEAR operatorSPECIFICATIONS:1.Flanges Connection:6.Face to Face:JIS 10K, ANSI 125LBS / 150LBS, BS10 Table EDesigned to meet ISO 5752 table 5 short.DIN PN10, ISO PN10 / PN16.7.Mounting Flange:2.Fluid Application:Designed to comply with ISO 5211, can beWater, Seawater, Sewage, Air, Oil, Powder, Gas.easily fitted with an actuator.3.Working Pressure: 10 kg/cm2 (150 PSI)8.50mm Thru 300mm in Octagon stem design to drive4.Test Pressure: (ISO-5208)the disc for open/close.Body :20 kg/cm2 (300 PSI) 24 kg/cm2 (340 PSI)9.350mm Thru 600mm in Square stem design to driveSeat :12 kg/cm2 (170 PSI) 18 kg/cm2 (255 PSI)The disc for open/close.5.Valve Sizes:50mm ～ 600mm are standard size.MATERIALS:Model:PartsLeverGearBF-WCB-26N /BF-WCB-28GBF-WCB-26S /BF-WCB-28SBF-WCB-26M /BF-WCB-28M1BodyCAST STEELCAST STEELCAST STEEL2LinerNBR / EPDM / VITONNBR / EPDM / VITONNBR / EPDM / VITON3StemSS 410SUS 304SUS 3164DiscDUCTILE IRONCF8CF8M5Taper Pin (14"-24")SUS 316SUS 316SUS 3166BushingNYLONNYLONNYLON7O-RingNBR - EPDMNBR – EPDMNBR - EPDMBody material: S/S316 (CF8M), S/S304 (CF8) available when required.当您使用的场合非常重要或环境比较复杂时,请您提供设计图纸和详细参数，我们的工程师专家会专心为您审核与分析。 我们可以为您提供专业的解决方案，包括设计、定做、成套、运行、服务。我们一直致力于阀门行业领域的*，为您提供的阀门知识、的服务、*的技术顾问。
|
销售部电话：021-61559758手机：13472856186销售部负责人：陈先生业务QQ：3059271438业务邮箱：3059271438@qq.com公司网址：www.ebrofluidvalves.cn台湾317产品适用于各个行业中的水、油、气、蒸汽等管道。常规产品常年备有现货，可通过快捷的运输方式交到客户手中。
